TRUK
136 MDLR
136 MDLR
| Maximum Speed | (Km/h) | 123 |
| Gradeability | (tan %) | 36,7 |
| Model | - | N04C-WY |
| Model Type | - | Mesin Diesel 4 Langkah Segaris; Variable Nozzle Turbocharger; Intercooler; Common Rail |
| Tenaga Maksimum | (PS/rpm) | 136 / 2.500 |
| Maximum power | (Kgm/rpm) | 40 / 1.400-2.500 |
| Number of cylinders | - | 4 |
| Diameter x Langkah Piston | (mm) | 104 x 118 |
| Fill the Cylinder | (cc) | 4,009 |
| Type | - | Pelat Kering Tunggal, dengan Coil Spring |
| Disc Diameter | (mm) | 300 |
| Type | - | RE50 |
| Number 1 | - | 5.342 |
| Number 2 | - | 2.975 |
| Number 3 | - | 1.604 |
| Number 4 | - | 1.000 |
| Number 5 | - | 0,712 |
| Number 6 | - | - |
| Back off | - | 4.970 |
| Type | - | Power Steering (Recirculating Ball Screw) |
| Minimal Rotating Radius | (m) | 8,1 |
| Front | - | Reverse Elliot, I-Section Beam |
| Back | - | Full Floating Tipe Hypoid Gear |
| Final gear comparison | - | 5,125 |
| Main Break | - | Vaccum Servo dengan sirkuit ganda; dilengkapi dengan Booster |
| Slow down brake | - | Terletak pada Pipa Gas Buang |
| Parking Brakes | - | Internal Expanding pada Output Shaft Transmission |
| Tire Size | - | 7.50-16-14PR |
| Rim Size | - | 16 x 6.00GS-127 |
| Number of Tires | - | 6 (+1) |
| Accu | (V-Ah) | 12V-100Ahx1 |
| Capacity | (L) | 100 |
| Wheelbase Spacing | WB (mm) | 4.200 |
| Total Length | OL (mm) | 7.820 |
| Total Width | OW (mm) | 1.955 |
| Total Height | OH (mm) | 2.155 |
| Front Footprint width | FR Tr (mm) | 1.455 |
| Rear Footprint width | RR Tr (mm) | 1.480 |
| Front Lip | FOH (mm) | 1.065 |
| Rear Lip | ROH (mm) | 2.555 |
| Cabin to Axle (CA) | CA (mm) | 3.730 |
| Front & back | - | Rigid Axle dengan Pegas Daun Semi Elliptic |
| Empty Weight | (kg) | 2.400 |
| Gross Combination Weight (GCW) | (kg) | 8.250 |
